Preface
- <Introduction Configuration>
<>Applicable products and software versions
This manual is intended for AX3660S. It also describes the functions of the software OS-L3M Ver. 12.1. The described function is that supported by the software and by optional licenses.
Before you operate the equipment, carefully read the manual and make sure that you understand all instructions and cautionary notes. After reading the manual, keep it in a convenient place for easy reference.
Unless otherwise noted, this manual describes features that are common to SL-L3A and SL-L3L software licensing. Functions that are not common are indicated by the following symbols.
- [SL-L3A]:
-
Description of the software licensing SL-L3A.
<>Corrections to this manual
Corrections to this manual might be contained in the Release Notes and Manual Corrections that come with the software.
Intended readers
This manual is intended for system administrators who wish to configure and operate a network system that uses the Switch.
Readers must have an understanding of the following:
-
The basics of network system management
<>URL of this documentation
You can view this manual on our website at:
https://www.alaxala.com/
<>Reading sequence of the manuals
The following shows the manuals you need to consult according to your requirements determined from the following workflow for installing, setting up, and starting regular operation of the Switch.
Abbreviations used in the manual
AC Alternating Current ACK ACKnowledge ADSL Asymmetric Digital Subscriber Line AES Advanced Encryption Standard ALG Application Level Gateway ANSI American National Standards Institute ARP Address Resolution Protocol AS Autonomous System BFD Bidirectional Forwarding Detection BGP Border Gateway Protocol BGP4 Border Gateway Protocol - version 4 BGP4+ Multiprotocol Extensions for Border Gateway Protocol - version 4 bit/s bits per second (can also appear as bps) BPDU Bridge Protocol Data Unit BRI Basic Rate Interface CA Certificate Authority CBC Cipher Block Chaining CC Continuity Check CDP Cisco Discovery Protocol CFM Connectivity Fault Management CIDR Classless Inter-Domain Routing CIR Committed Information Rate CIST Common and Internal Spanning Tree CLNP ConnectionLess Network Protocol CLNS ConnectionLess Network System CONS Connection Oriented Network System CRC Cyclic Redundancy Check CSMA/CD Carrier Sense Multiple Access with Collision Detection CSNP Complete Sequence Numbers PDU CST Common Spanning Tree DA Destination Address DC Direct Current DCE Data Circuit terminating Equipment DES Data Encryption Standard DHCP Dynamic Host Configuration Protocol DIS Draft International Standard/Designated Intermediate System DNS Domain Name System DNSSL Domain Name System Search List DR Designated Router DSA Digital Signature Algorithm DSAP Destination Service Access Point DSCP Differentiated Services Code Point DSS Digital Signature Standard DTE Data Terminal Equipment DVMRP Distance Vector Multicast Routing Protocol E-Mail Electronic Mail EAP Extensible Authentication Protocol EAPOL EAP Over LAN ECDHE Elliptic Curve Diffie-Hellman key exchange, Ephemeral ECDSA Elliptic Curve Digital Signature Algorithm EFM Ethernet in the First Mile ES End System FAN Fan Unit FCS Frame Check Sequence FDB Filtering DataBase FQDN Fully Qualified Domain Name FTTH Fiber To The Home GCM Galois/Counter Mode GSRP Gigabit Switch Redundancy Protocol HMAC Keyed-Hashing for Message Authentication HTTP Hypertext Transfer Protocol HTTPS Hypertext Transfer Protocol Secure IANA Internet Assigned Numbers Authority ICMP Internet Control Message Protocol ICMPv6 Internet Control Message Protocol version 6 ID Identifier IEC International Electrotechnical Commission IEEE Institute of Electrical and Electronics Engineers, Inc. IETF the Internet Engineering Task Force IGMP Internet Group Management Protocol IP Internet Protocol IPCP IP Control Protocol IPv4 Internet Protocol version 4 IPv6 Internet Protocol version 6 IPV6CP IP Version 6 Control Protocol IPX Internetwork Packet Exchange ISO International Organization for Standardization ISP Internet Service Provider IST Internal Spanning Tree L2LD Layer 2 Loop Detection LAN Local Area Network LCP Link Control Protocol LED Light Emitting Diode LLC Logical Link Control LLDP Link Layer Discovery Protocol LLQ+3WFQ Low Latency Queueing + 3 Weighted Fair Queueing LSP Label Switched Path LSP Link State PDU LSR Label Switched Router MA Maintenance Association MAC Media Access Control MC Memory Card MD5 Message Digest 5 MDI Medium Dependent Interface MDI-X Medium Dependent Interface crossover MEP Maintenance association End Point MIB Management Information Base MIP Maintenance domain Intermediate Point MLD Multicast Listener Discovery MRU Maximum Receive Unit MSTI Multiple Spanning Tree Instance MSTP Multiple Spanning Tree Protocol MTU Maximum Transmission Unit NAK Not AcKnowledge NAS Network Access Server NAT Network Address Translation NCP Network Control Protocol NDP Neighbor Discovery Protocol NET Network Entity Title NLA ID Next-Level Aggregation Identifier NPDU Network Protocol Data Unit NSAP Network Service Access Point NSSA Not So Stubby Area NTP Network Time Protocol OADP Octpower Auto Discovery Protocol OAM Operations,Administration,and Maintenance OSPF Open Shortest Path First OUI Organizationally Unique Identifier packet/s packets per second (can also appear as pps) PAD PADding PAE Port Access Entity PC Personal Computer PCI Protocol Control Information PDU Protocol Data Unit PGP Pretty Good Privacy PICS Protocol Implementation Conformance Statement PID Protocol IDentifier PIM Protocol Independent Multicast PIM-DM Protocol Independent Multicast-Dense Mode PIM-SM Protocol Independent Multicast-Sparse Mode PIM-SSM Protocol Independent Multicast-Source Specific Multicast PMTU Path Maximum Transmission Unit PRI Primary Rate Interface PS Power Supply PSNP Partial Sequence Numbers PDU PTP Precision Time Protocol QoS Quality of Service QSFP+ Quad Small Form-factor Pluggable Plus QSFP28 28Gbps Quad Small Form factor Pluggable RA Router Advertisement RADIUS Remote Authentication Dial In User Service RDI Remote Defect Indication RDNSS Recursive Domain Name System Server REJ REJect RFC Request For Comments RIP Routing Information Protocol RIPng Routing Information Protocol next generation RMON Remote Network Monitoring MIB RPF Reverse Path Forwarding RQ ReQuest RSA Rivest, Shamir, Adleman RSTP Rapid Spanning Tree Protocol SA Source Address SD Secure Digital SDH Synchronous Digital Hierarchy SDU Service Data Unit SEL NSAP SELector SFD Start Frame Delimiter SFP Small Form factor Pluggable SFP+ enhanced Small Form-factor Pluggable SHA Secure Hash Algorithm SMTP Simple Mail Transfer Protocol SNAP Sub-Network Access Protocol SNMP Simple Network Management Protocol SNP Sequence Numbers PDU SNPA Subnetwork Point of Attachment SPF Shortest Path First SSAP Source Service Access Point SSH Secure Shell SSL Secure Socket Layer STP Spanning Tree Protocol Sync-E Synchronous Ethernet TA Terminal Adapter TACACS+ Terminal Access Controller Access Control System Plus TCP/IP Transmission Control Protocol/Internet Protocol TLA ID Top-Level Aggregation Identifier TLS Transport Layer Security TLV Type, Length, and Value TOS Type Of Service TPID Tag Protocol Identifier TTL Time To Live UDLD Uni-Directional Link Detection UDP User Datagram Protocol UPC Usage Parameter Control UPC-RED Usage Parameter Control - Random Early Detection VLAN Virtual LAN VNI VXLAN Network Identifier VPN Virtual Private Network VRF Virtual Routing and Forwarding/Virtual Routing and Forwarding Instance VRRP Virtual Router Redundancy Protocol VTEP VXLAN Tunnel End Point VXLAN Virtual eXtensible Local Area Network WAN Wide Area Network WDM Wavelength Division Multiplexing WFQ Weighted Fair Queueing WRED Weighted Random Early Detection WS Work Station WWW World-Wide Web
<>Conventions: KB, MB, GB, and TB
This manual uses the following conventions: 1 KB (kilobyte) is 1024 bytes, 1 MB (megabyte) is 10242 bytes, 1 GB (gigabyte) is 10243 bytes, 1 TB (terabyte) is 10244 bytes.
